Forged Steel Globe Valve IBR & NON-IBR (800/1500/2500 Class)

Features:

• ⇒ OS & Y Type, Bolted Bonnet.
• ⇒ Design Std: BS 5352/ANSI B 16.34
• ⇒ Low operating Torque.
• ⇒ Valves with Back seat arrangement.
• ⇒ Screwed to BSP as per BS 21/ANSI/ASME B 1.20 NPT./
• ⇒ Socket weld to B 16.11/ Butt weld ends as per B 16.25.

On Request:

• ⇒ Full Bore construction.
• ⇒ Extended Bonnet for Cryogenic Services.
• ⇒ Locking arrangement.
• ⇒ NACE as per MR-01-75
• ⇒ Welded Bonnet.
• ⇒ Stellited/ Hard Faces.

Please Consult Us For:

• ⇒ High Temperature /Cryogenic Services.
• ⇒ Other Material.
• ⇒ Other trim Material.

Material of Construction:

• ⇒ Body: A105/F11/F22/A 182 Gr. 304/F316/LF2/Duplex Bonnet:
• ⇒ A105/F11/F22/A 182 Gr. 304/F316/LF2/Duplex
• ⇒ Gasket: Sp. Wound SS 304/ SS 316 with graphite/PTFE Filter.
• ⇒ Gland Packing: Graphoil.
• ⇒ Plug: 13% Cr./ SS 304/ SS 316
• ⇒ Seat: 13% Cr. SS 304/ SS 316/Stellite
• ⇒ Stem: SS 410/ SS 304/ SS 316/Monel
• ⇒ Gland Flange: SS 410/ SS 304/ SS 316/Monel.
• ⇒ Yoke Sleeve: SS 410/ SS 304/ SS 316/Monel
• ⇒ Hand wheel: Malleable Iron/ Cast steel.
